linear potentiometers/linear sensors
conductive plastic
with front extended shaft
model
18flpbc25、18flpbc50、18flpbc75、18flpbc100、18flpbc150
standard resistance values
500,1k,2k,5k,10k,20k
total resistance tolerance
±10%(k)
independent linearity tolerance
standard class ±0.5%, precision class ±0.2%、±0.1%、±0.05%
resolution
essentially infinite
output smoothness
contact resistance variation
<2%c.r.v.
power rating
0.5w、0.75w、1.0w、1.25w、1.5w
electrical stroke
25±1mm、50±1mm、75±1mm、100±1mm、150±1mm
mechanical stroke (ms)
about30mm、55mm、80mm、105mm、155mm
insulation resistance
>1000mω(500v.d.c.)
dielectric strength
1 minute at 1,000v.a.c.
friction
<1.2n(120gf)
stopper strength
approx. 90n(9kgf)
resistance temperature coefficient
±400p.p.m./℃
mass
approx. 90g、120g、140g、160g、250g
special stroke
stroke 200mm (s18flbc200)
special structure
sealed type (ip54, the length of "a" is extended by abt. 6mm.)
special taps
extra tap (available up to 1 tap and only on the version with a connector.)
other
with leadwire terminals (dimensions are as the right drawing. dimensions of "a" and "l" are the same as the above table. length of lead wires is 1m.)
