hall effect joystick
metal housing case & small-sized
various output signals and output characteristics
operating angle
approx. ±15°(from center position)
operating force
approx. 2.5n~6n
max. operating force
100n
mechanical life expectancy
approx. 5,000,000
operating temperature range
-20℃~ 65℃
storage temperature range
-20℃~ 65℃
mass
approx. 125g
protection grade
ip65 (above panel)
input voltage
5v±10%;15~30v ;15~30v
output signal
0~100%vcc;0~10v;4~20ma
current consumption (no-load)
<16ma;<25ma;<35ma
load resistance
>100kω;>100kω;<600ω
output deviation at both ends
<1%·vcc;<50mv;<0.05ma
independent linearity tolerance
±2%
resolution
4096 (12bit)
dielectric strength
1 min (500v.a.c.)
insulation resistance
>1000mω (500v.d.c.)
overvoltage protection
<20v.d.c.
ems
10v/m (80mhz~1ghz 1khz 80%)
color
red;black;green;white;yellow
title
vcc;gnd;sw;x;y
special analog signals
9~30v applied, 0~5v output;10v applied, 0~10v output;3.3v applied, 0~5v output;dual analog signal and pwm
other output signals
ssi, rs485, canopen, usb, modbus, wireless conmunication(lora), other digital signal, bus signal, etc.
special knob
customized knob, with push button switch (with light is optional), with other microswitches models, etc.
other special specifications
with deutsch connector (6pin);with control module
