3-dimensional coordinate type joystick
hall effect joystick
low-cost
controlling range of operating lever
3-dimensional coordinate type, x and y directions: approx. ±20° from center position, z direction : approx.±30° from center position
operating force
standard spring return device (automatically return to center), x and y directions: approx.1~4n(100~400gf)
operating temperature range
z direction : approx.40~80mn・m(400~800gf・cm)40~60mn·m(400~600gf·cm)
vibration
-20℃~ 60℃
shock
10~55hz,98m/s2
mechanical life expectancy
294m/s2
mass
approx. 5,000,000 operations for x and y axes, approx. 3,000,000 operations for z axis.
type
hall effect ic type resistive element incorporated
applied voltage
5v±10%
effective output
approx.0.5v~4.5v
electrical rotating angle
x and y-axis: approx.±20°, z-axis: approx.±30°
independent linearity tolerance
±3%
load resistance
>10kω
dielectric strength
1 minute at 500v.a.c.
insulation resistance
>1000mω(500v.d.c)
ems durability
100v/m (80mhz〜6ghz based on iso11452-1〜-3)
esd durability
±8kv contact ±15kv aerial discharge (based on iec61000-4-2)
