3-dimensional coordinate type joystick
potentiometer outside-mounted
hall effect joystick
controlling range of operating lever
2-dimensional coordinate type: omni-directionally approx.±22°~±26°operation from center position. 3-dimensional coordinate type: approx.±45°~50°operation from center position of knob in addition to the operating range of 2-dimensional coordinate type.
operating force
standard spring return device : automatically return to center (omni-directional type), x and y directions:
operating temperature range
approx.2 ~ 12n(200 ~ 1200gf), z direction: approx.20 ~ 85mn・m(200 ~ 850gf・cm)
vibration
-20℃~ 65℃
shock
10~55hz,98m/s2
mechanical life expectancy
294m/s2
mass
approx.10,000,000 operations
type
hall effect ic type potentiometer (shsm18e) incorporated
applied voltage
5vdc±10%
effective output
0.5v~4.5v
electrical rotating angle
x and y-axis: approx.±22°, z-axis: approx.±45°
independent linearity tolerance
±3%fs
load resistance
>10kω
resolution
infinitesimal
dielectric strength
1 minute at 250v.a.c.
insulation resistance
>100mω(250v.d.c)
ems durability
100v/m(80mhz~1ghz 1khz sine-wave 80%am modulation)
esd durability
±8kv contact ±15kv aerial discharge (based on iec61000-4-2)
