multi-turn
hybrid
bushingmount&servomount
standard resistance range
2k,5k,10k,20k,50k(ω)
max. practical resistance value
100kω
total resistance tolerance
standard class ±10%(k), precision class ±5%(j)
independent linearity tolerance
standard class ±0.4%, precision class ±0.1%(±0.2% in case of within 5kω)
resolution
essentially infinite
output smoothness
contact resistance variation
<5%c.r.v.
power rating
1.0w
electrical travel
3600°±5°
mechanical travel
3600°
insulation resistance
>1000mω(500v.d.c.)
dielectric strength
1 minute at 1,000v.a.c.
starting torque
<3mn•m(30gf•cm)(bushingmount type)、<2mn•m(20gf•cm)(servomount type)
stopper strength
approx.0.15n•m(1.5kgf•cm)
appropriate fastening torque of the nut
<0.8mn•m(8kgf•cm)
resistance temperature coefficient
±100p.p.m./℃
mass
approx.10g
special turns
5-turn type (s12hhp-5)
special resistance value
shaft with front and rear extension (rear shaft with 0.8mm dia. and 10mm length), special machining on the shaft
special housing case
simple sealed housing (in case of servomount type, the housing length becomes longer by 1.2mm.)
