multi switch type
knob configured with 6 up to 8 push button switches
switch type
6 button switches at most and 1 dead-man switch
thumb joystick type
1 thumb joystick, 2 button switches at most and 1 dead-man switch
matching joystick
sakae: 50jc sentop: jp50、jh50;sakae: 90ja、90jb ;other joystick;be used alone"
operating force
approx. 3.1n
applied voltage
5v±0.01v
output signal
0~5v(available for other output ranges)
life expectancy
>1,000,000
protection degree
ip68
type
button switch;dead-man switch
rating
48v.d.c. / 0.1a;30v.d.c. / 0.1a
life expectancy
approx. 100,000;approx. 100,000
insulation resistance
>1000mω (500v.d.c.);>100mω (500v.d.c.)
dielectric strength
1min (1000v.a.c.);1min (600v.a.c.)
protection degree
ip67 ;ip40
