电位器型操纵杆

浏览量: tiempo: 2023-01-09

    características:

  • 3-dimensional coordinate type joystick

  • potentiometer outside-mounted type

  • with conductive plastic element

  • with spring return device

50jak-国际云顶yd4008


controlling range of operating lever

2-dimensional coordinate type : omni-directionally approx.±30°~±35°, operation from center position. 3-dimensional coordinate type : approx. 320° rotation by knob-operation in addition to the controlling range of 2-dimensional coordinate operation. (in case of center-returning type with spring return device, the operating range is approx. ±45°~±50° from center position.)

operating force

without spring return device. standard : approx. 0.5~0.8n (50~80gf.), high torque type : approx. 2~6n (200~600gf.), with spring return device : (subject to directivity), x, y directions : approx. 0.8~1.5n (80~150gf), z direction : approx. 20~85mn~m (200~850gf・cm.)

operating temperature range

-20℃~ 65℃

vibration

10~55hz,98m/s2

shock

294m/s2

life expectancy

approx. 5,000,000 operations

mass

2-dimensional coordinate type : approx. 280g, 3-dimensional coordinate type : approx. 230g

potentiometers mounted

sfcp22e 10k ω±15%, 0.2w (conductive plastic resistive element), independent linearity tolerance ±3%, - for x and y axes : electrical rotating angle : approx. 60°, - for z axis : electrical rotating angle : approx. 320°, - in case of spring return type for z axis : electrical rotating angle approx. 90°, all terminals can be fitted with the tyco 110 series fasten receptacle (2.8 × 0.5mm) or equivalents. - in case of 3-dimensional coordinate z-axis potentiometer inside-knob incorporated type (t-type), the following potentiometer is used : sfcp12ac 10kω ±15%, independent linearity tolerance ±3%, 0.06w (electrical rotating angle : approx. 90°)

output smoothness

<against input voltage 0.2%

contact resistance variation

<5%c.r.v

resolution

essentially infinite

dielectric strength

1 minute at 500v.a.c.

insulation resistance

>1000mω(500v.d.c)
