sibo se ha enfocado en potenciómetros y sensores durante 27 años.

producto joysticks joysticks tipo potenciómetro

devolver
jp45
jp45

jp45

potentiometer-type joysticks

浏览量： tiempo: 2023-03-03

    características：

  • imported potentiometer incorporated

  • various knobs available

  • various output signals

jp45-国际云顶yd4008


operating angle

approx. ±42.5°（from center position）

operating force

approx. 3.5n~5n

max. operating force

100n

mechanical life expectancy

approx. 10,000,000

operating temperature range

-20℃~ 85℃

storage temperature range

-20℃~ 85℃

mass

approx. 300g

protection grade

ip54

standard resistance value

10k±15%

independent linearity tolerance

±3%

output smoothness

against input voltage 0.2%

contact resistance variation

<5%crv

resolution

essentially infinite

power rating

0.2w

dielectric strength

1 min (500v.a.c.)

insulation resistance

>1000mω (500v.d.c.)

ems

10v/m (80mhz~1ghz 1khz 80%)

special knob

special knob and motifs on the knob

other special specifications

with customer-specific connectors；with protection module
