introduction of sibo small-国际云顶yd4008

2023-06-02

22 family - the new favorite with ‘beauty and wisdom’ ;

25 family - ‘fingertip dancers, flexible and firm’ ;

30 family - ‘strong genes, each one can stand on their own’


introduction of sibo miniature joystick


with the continuous acceleration of the development of modern society, automated equipment in various industries is moving towards high-tech fields. in addition to fully automatic control, many links also require human control, and ‘joysticks’ occupy a large part of the market!


friends who are familiar with sibo will know that sibo has been committed to the research, development, production and sales of sensors and peripheral products; joysticks are one of the main characters in our main products, our joysticks have many types, functions and good performance, especially the small-sized joysticks have more diverse options. today, please follow the editor to learn about it and see if there is your favorite!


22 family - the new favorite with ‘beauty and wisdom’


introduction of sibo small-sized joysticks(图1)


jh22a and jh22b are two brothers in the 22 family, they are sibo’s new favorites, they are finger-operated single-axis joysticks, it is not an exaggeration to describe them as ‘beautiful and smart’ in english.


‘beautiful’ in the handle can not only return to the center, but also achieve mechanical locking at the end. if there are other needs, it can be customized;


‘smart’ in the internal use of non-contact structure principle, long service life, high protection level;


‘smart’ in the output signal is diverse and highly customizable, can output single-channel, common-source dual-channel and independent dual-channel signals, pwm signals are optional, and can also output switch signals at specific positions;


such a ‘small and smart’ joystick is favored by industries such as engineering machinery, engineering vehicles, agricultural and forestry machinery, etc., usually used to control remote control boxes; if you also like it, please contact us _!


25 family - ‘fingertip dancers, flexible and firm’


introduction of sibo small-sized joysticks(图2)


jh25 is the only member of the 25 family, and also the smallest member of sibo’s many joysticks. its upper end size is only about φ25mm, height 20mm, and the lower end is also only 20mm, occupying very little space, so the space requirements for the installation equipment are very small, and it is very friendly to any equipment with space limitations! jh25 is like a ‘fingertip dancer, flexible and firm’ in english.


‘flexible’ in the top uses a ‘castle-shaped’ handle, which fits better with your thumb, and the thumb operation will be smooth, light and agile like a dancer!


‘firm’ in the high structural strength, can withstand up to 20kg of extreme operating force, and the internal use of a closed structure, the electrical part of the protection level can also reach ip67;


in addition to the ‘flexible and firm’ beauty, jh25’s inner beauty is also very eye-catching, using a non-contact structure principle, long service life, and can output single-channel and dual-channel signals, pwm signals are optional, output signal amplitude can also be customized according to customer needs!


30 family - ‘strong genes, each one can stand on their own’


01 twin brothers ‘30jb and 30je’


introduction of sibo small-sized joysticks(图3)


from the appearance, these two brothers look exactly the same, with a very classic shape, which can meet the usage habits of most application markets;


30jb uses sakae’s precision brushes and resistive substrates, with a compact and reliable structure, and has undergone long-term tests in the harsh environment of the engineering machinery industry, with very excellent performance;


30je takes a different path and adopts the characteristic of pure ‘switch output’, opening up another world!


02 ‘rising star’ jh30 strikes out


introduction of sibo small-sized joysticks(图4)


the 30 family has many members, and jh30 definitely deserves to be a rising star, focusing on quality, innovative structure, and stable output! the unique ‘small backpack’ design makes jh30’s structure compact and small in size, very suitable for use in places where installation space is limited; the product focuses on dual-axis self-reset operation, although the space is small, jh30 does not lack the spirit of facing difficulties, can customize ‘single-axis friction positioning’ operation; internal use of hall principle; can output various customizable current and voltage signals, customization content includes signal curve type, signal amplitude, etc., pwm signal is optional, dual-channel redundant output is optional, we can also provide various types of bus output products, such as rs485 , canbus, usb, etc., the protocol can be customized according to customer requirements.


上海思博,给您拜年啦!(图2)

welcome to use wechat to scan the qr code, add exclusive customer service for sibo, and obtain more information.


more information




shanghai sibo m&e co., ltd is a renowned enterprise and recognized by numerous awards such as shanghai high-tech enterprise, shanghai "specialized and innovative" enterprise, shanghai sms enterprise, shanghai class aaa contract credit enterprise, class a taxpayer enterprise, and shanghai advanced private enterprise. meanwhile sibo has achieved quality management certification iso9000.the company's products have been exported to overseas markets such as southeast asia, europe and the united states for a long time. there are thousands of types of products, including potentiometers, joysticks, pedals, draw wire sensors, encoders, handwheels, and signal communication modules. welcome to inquire and patronize!
