model no.

ksm22f, ksm22fi, ksm22fs

current consumption

approx. 3.5ma

independent linearity tolerance

±0.5%fs(fs=100°)

mechanical rotating angle

360°(endless)

effective electrical angle

±50°(100°)

applied voltage

5v.d.c.

load resistance

>10kω

effective output

approx.10％～90％ vin・fs(fs=100°)

output temperature characteristics

within ±2.5％ vout･fs

drift at center position

within ±0.5％ vout･fs

operating temperature range

-40°c～ 105°c

storage temperature range

-40°c～ 105°c

mass

approx.15g

rotating torque

<1mn·m(10gf·cm)、<3mn·m(30gf·cm)、<0.2mn·m(2gf·cm)

model no.

ksm22f, ksm22fi, ksm22fs

thermal shock

5 cycles -50°～ 105°

exposure at low temperature

24 hours at -50°c

exposure at high temperature

1,000 hours at 105°c

moisture resistance

40℃　95％rh　120 hours

vibration

10～2,000hz　196m/s2　12 hours

shock

980m/s2(18 times)

rotational life expectancy

approx. 100,000,000, approx. 10,000,000, approx. 200,000,000

special applied voltage

possible to meet with from 3v.d.c. to 10v.d.c.

special effective electrical rotating angle

possible to meet with from ± 25゜to ± 80゜

special shaft type

special machining on the shaft
