magnetic rotary sensor (hall effect)
single turn
bushingmount
current consumption
approx. 7ma
independent linearity tolerance
±1.5%fs(fs=90°)
mechanical rotating angle
360°(endless)
effective electrical angle
±45°(endless)
applied voltage
5v±10%d.c.
load resistance
>10kω
effective output
approx. 10%~approx. 90%vin・fs(fs=90°)
output temperature characteristics
within ±2.5%vout/fs
drift at center position
within ±0.5%vout/fs
operating temperature range
- 40°c~ 105°c
storage temperature range
- 40°c~ 105°c
mass
approx. 15g
rotating torque
<2mn·m(20gf·cm)
thermal shock
5 cycles -50°c~ 105°c
exposure at low temperature
24 hours at -50°c
exposure at high temperature
1,000 hours at 105°c
vibration
10~2000hz 196m/s2
shock
980m/s2 6ms
rotational life expectancy
approx. 50,000,000
ems tolerance
50v/m(80mhz~1ghz 1khz sinwave80% amplitude modulation)
esd tolerance
±4kv contact discharge /±4kv aerial discharge (based on iec 61000-4-2)
special effective electrical angle
possible to meet with from ± 10°to ± 45°by 5°step, as requested
special shaft type
special machining on the shaft, special output
