current consumption

single output: approx.7ma, dual output: approx.14ma

independent linearity tolerance

±1.5%fs(fs=90°)

mechanical rotating angle

360°(endless)

effective electrical angle

±45°(endless)

applied voltage

5v±10%d.c.

load resistance

>10kω

effective output

approx. 10%～approx. 90%vin・fs(fs=90°)

output temperature characteristics

within ±2.5%vout/fs

drift at center position

within ±0.5%vout/fs

operating temperature range

- 40°c～ 105°c

storage temperature range

- 40°c～ 105°c

mass

approx. 15g

rotating torque

<2mn·m(20gf·cm)

thermal shock

5 cycles -50°c～ 105°c

exposure at low temperature

24 hours at -50°c

exposure at high temperature

1,000 hours at 105°c

vibration

10～2000hz 196m/s2

shock

980m/s2 6ms

rotational life expectancy

approx. 50,000,000

ems tolerance

100v/m(80mhz～1ghz 1khz sinwave80% amplitude modulation)

esd tolerance

±8kv contact discharge /±15kv aerial discharge (based on iec 61000-4-2)

special effective electrical angle

possible to meet with from ± 10°to ± 45°by 5°step, as requested

special shaft type

special machining on the shaft, special output (hsm18e & el are only available - cross, parallel)
