magnetic rotary sensor (hall effect)
high protection degree
heavy-duty
antimagnetic interference
shielded cable
reverse connect protection
mechanical angle
360º(endless)
protection degree
ip67
operating torque
≤50mn·m
max.speed
12000rpm
life expectancy
100,000,000
mass
approx.330g
housing material
anodized aluminium alloy
shaft material
stainless steel
shaft load
axial 40n,radial 80n
shaft diameter
φ6/ φ8/ φ10/ φ12
operating temperature range
-30℃~ 85℃
storage temperature range
-30℃~ 85℃
esd durability
contact discharge ±8kv,aerial discharge ±15kv,en61000-4-2:2009
ems durability
100v/m (80mhz~1ghz,1khz80% amplitude modulation),en61000-4-3:2006 a1:2010
standard model
r58 2410 w360(for more input voltage/output signal such as 2405、2442, please check our catalog.)
input voltage
15~30v
output signal
0~10v
current consumption (no-load)
<25ma
output deviation of both ends
<50mv
load resistance
>100kω
effective electrical angle
360º
independent linearity tolerance
±0.3%
resolution
4096 (12 bit)
update rate
0.3ms
insulation resistance
> 1000mω (500v.d.c)
dielectric strength
1 min (500v.a.c)
2410
15~30v / 0~10v
2405
9~30v / 0~5v
2442
15~30v / 4~20ma
other output signals
available for incremental、pwm、ser、ssi、spi signal.
special shaft
special length of shaft、special diameter or special machining on shaft (like shaft slotted、fatted etc.) and blind hole product.
