sibo занимается потенциометрами и датчиками уже 27 лет.

db10-26b
db10-26b

db10-26b

digital-readout dials

浏览量: вернуться: 2023-01-09

    характеристики:

  • digital-readout

db10-国际云顶yd4008


number of turns-counting.

10

max. indication

999

matching shaft dia. (mm)

standard 6, special 3, 3.175, 4, 6.35

combinable helicalohm pot.

(matching shaft length of 25mm) 20hp, 46hd, 22hp, 20hhp, 22hhp, 25hp

standard color of case

ivory

flexible coupling

yes

lock device

yes

operating temperature range

-30℃~ 85℃

mass

approx.60g

number of turns-counting.

10

max. indication

999

matching shaft dia. (mm)

standard 6, special 3, 3.175, 4, 6.35

combinable helicalohm pot.

(matching shaft length of 25mm) 20hp, 46hd, 22hp, 20hhp, 22hhp, 25hp

standard color of case

silver

flexible coupling

yes

lock device

yes

operating temperature range

-30℃~ 85℃

mass

approx.60g

number of turns-counting.

10

max. indication

999

matching shaft dia. (mm)

standard 6, special 3, 3.175, 4, 6.35

combinable helicalohm pot.

(matching shaft length of 25mm) 20hp, 46hd, 22hp, 20hhp, 22hhp, 25hp

standard color of case

silver

flexible coupling

no

lock device

yes

operating temperature range

-30℃~ 85℃

mass

approx.60g

number of turns-counting.

100

max. indication

999

matching shaft dia. (mm)

standard 6, special 3, 3.175, 4, 6.35

combinable helicalohm pot.

(matching shaft length of 25mm) 20hp, 46hd, 22hp, 20hhp, 22hhp, 25hp

standard color of case

ivory

flexible coupling

yes

lock device

yes

operating temperature range

-30℃~ 85℃

mass

approx.60g

special color

special colors on housing and spin plate on the top of the knob (black, etc.)

specially face plate

special graduation such as with a decimal point, comma, etc
