xl50sb
xl50sb

xl50sb

draw wire sensor

浏览量： вернуться: 2023-01-29

    характеристики：

  • draw-wire position sensor

  • economy version

  • measuring rang：100~1500mm

  • output signal：modbus rtu、canopen

xl50sb-国际云顶yd4008


measure range

max. 1500mm

protection degree

ip54（electrical parts）

force

2n~5.5n

mechanical life expectancy

2,000,000

mass

approx.350g

housing material

anodized aluminium alloy

draw wire

0.6mm coated polyamid stainless steel

max. reciprocating speed

300mm/s

the length of the cable

1.5m

operating temperature range

-30℃～ 85℃

storage temperature range

-30℃～ 85℃

shock

10g, 10hz~1.5khz

vibration

50g, 10ms

applied voltage

5v±10%、12~30v

output port

rs485、can

output signal

modbus rtu、canopen

linearity tolerance

0.3%fs

repeatability accuracy

0.03%

single-turn resulation

0.2mm (standard)、0.025mm (optional)

special specifications

available for multi-segment output, special cables, high protection degree, etc.
