automatically return to center
with spring return device
-10v~10v voltage output, v-type voltage output and current output
mid relay signal (voltage output)
operating angle
±30°~± 35°(from center position)
operating method
with spring return device
operating force
approx. 3n~15n
maximum allowable force
300n
mechanical life expectancy
approx. 5,000,000
operating temperature
-20℃~ 65℃
storage temperature
-40℃~ 85℃
mass
approx. 370g
protection degree
ip54(above panel)
24v/0v
power
out /out-
output analog signal
com
relay switch.com
r
relay switch.' 'direction
zr
relay switch.middle position
-r
relay switch.'-'direction
input voltage
24v.d.c.
output signal
1.voltage output (range adjustable);2.mid relay signal (<±3°) ;3.forward and backward relay signal (<-3° or >3°)
relay rating
250v.a.c. / 5a
load resistance
>100kω
dielectric strength
1 min (500v.a.c.)
insulation resistance
>1000mω (500v.d.c.)
overvoltage protection
<20v.d.c.
reverse polarity protection
<-10v.d.c.
input voltage
24v.d.c.
output signal
1.voltage output (range adjustable);2.mid relay signal (<±3°) ;3. forward and backward relay signal (<-3° or >3°)
relay rating
250v.a.c. / 5a
load resistance
>100kω
dielectric strength
1 min (500v.a.c.)
insulation resistance
>1000mω (500v.d.c.)
overvoltage protection
<20v.d.c.
reverse polarity protection
<-10v.d.c.
input voltage
24v.d.c.
output signal
current output 4~20ma (range adjustable)
load resistance
<500ω
dielectric strength
1 min (500v.a.c.)
insulation resistance
>1000mω (500v.d.c.)
overvoltage protection
<20v.d.c.
reverse polarity protection
<-10v.d.c.
