sibo занимается потенциометрами и датчиками уже 27 лет.

продукт педали педали потенциометрического типа

вернуться
c70fca
c70fca

c70fca

potentiometer-type pedals

浏览量： вернуться: 2023-01-09

    характеристики：

  • accelerator pedal

  • coductive plastic potentiometer type

  • metal case with high reliability

c70fca-国际云顶yd4008


operating angle

approx. 22°

operating force

15～27n

mechanical life expectancy

5,000,000

operating temperature

-30℃~ 70℃

storage temperature

-30℃~ 70℃

vibration

10~55hz 98m/s²

shock

294m/s²

mass

approx. 1100g

protection degree

ip54

standard resistance

10kω±20%, 5kω±20%

effective electrical angle

approx. 60°

independent linearity tolerance

±3%

resolution ratio

essentially infinite

power rating

0.25w

output smoothness

contact resistance variation

<5%crv

insulation resistance

>1000mω (500v.d.c)

dielectric strength

1 min (500v.a.c)

color

red，black，white

title

vcc，gnd，out

electrical specifications

pot. with other resistance(1k, 2k), special output characteristic, speical cable length, etc."

other special specifications

with matching signal module
