sibo занимается потенциометрами и датчиками уже 27 лет.

sbs022
sbs022

sbs022

signal converter

浏览量: вернуться: 2023-01-09

    характеристики:

  • non isolated power

  • economy version

  • optional output signal: 4~20ma、0~10v

sbs022-国际云顶yd4008


protection degree

ip20

installation mode

guide rail 35mm (din en 50022)

housing material

plastic (white)

operating temperature range

-25℃~ 85℃

storage temperature range

-25℃~ 105℃

resistance range

1kω~500kω

applied voltage

15~35vdc.

output signal

0~10v / 4~20ma

rated current

≤30ma

accuracy

±0.1%

load resistance

>5kω(voltage output);<600ω(current output)

resolution

essentially infinite

dielectric strength

1000v.a.c/1 min
